Custom Haynes 230 Parts Manufacturing
Precision CNC Machining of High-Temperature Nickel-Chromium-Tungsten Alloy
Expert manufacturing of Haynes 230 alloy components with superior high-temperature strength, oxidation resistance, and thermal stability for demanding aerospace and power generation applications.
Haynes 230 Alloy Overview
Haynes 230 is a nickel-chromium-tungsten-molybdenum alloy that offers exceptional high-temperature strength and oxidation resistance. This solid-solution strengthened alloy maintains excellent mechanical properties at temperatures up to 2100°F (1150°C).
- •Outstanding high-temperature strength
- •Superior oxidation resistance
- •Excellent thermal stability
- •Good fabricability and weldability
- •Long-term structural stability
Material Properties
Superior High-Temperature Performance
Chemical Composition
- •Nickel: 57% (base)
- •Chromium: 22%
- •Tungsten: 14%
- •Molybdenum: 2%
- •Iron: 3% max
- •Carbon: 0.10% max
Mechanical Properties
- •Tensile Strength: 125-155 ksi (860-1070 MPa)
- •Yield Strength: 85-115 ksi (590-790 MPa)
- •Elongation: 40-50%
- •Hardness: 200-250 HB
- •Density: 8.97 g/cm³
Thermal Properties
- •Melting Point: 2410°F (1320°C)
- •Maximum Service Temperature: 2100°F (1150°C)
- •Thermal Expansion: 7.4 x 10⁻⁶/°F
- •Thermal Conductivity: 8.1 BTU/ft·hr·°F
Manufacturing Processes
Advanced Machining Techniques for Haynes 230
CNC Milling
Precision milling with specialized tooling and cutting parameters optimized for Haynes 230's work-hardening characteristics.
Capabilities:
- •High-speed machining
- •Advanced coolant systems
- •Specialized carbide tools
- •Optimized cutting parameters
CNC Turning
Precision turning operations with careful attention to surface finish and dimensional accuracy.
Capabilities:
- •Multi-axis turning
- •Surface finish optimization
- •Tight tolerance control
- •Work-hardening management
5-Axis Machining
Complex geometry machining with simultaneous 5-axis operations for intricate Haynes 230 components.
Capabilities:
- •Complex geometry capability
- •Reduced setup time
- •Superior surface finish
- •Enhanced accuracy
Swiss Machining
High-precision Swiss machining for small, complex Haynes 230 parts with tight tolerances.
Capabilities:
- •Micro-precision machining
- •Complex geometries
- •Tight tolerances
- •High-volume production
Applications
High-Temperature Performance Solutions
Aerospace
Turbine components, combustion chambers, exhaust systems, and high-temperature structural parts.
Power Generation
Gas turbine components, heat exchangers, boiler tubes, and steam turbine parts.
Industrial Processing
Furnace components, heat treatment equipment, and high-temperature processing machinery.
Chemical Processing
Reactor vessels, heat exchangers, and corrosion-resistant equipment.
Why Choose Our Haynes 230 Manufacturing
Expertise in High-Temperature Alloys
Specialized Expertise
Deep knowledge of Haynes 230 machining characteristics and optimal processing parameters.
Advanced Equipment
State-of-the-art CNC machines equipped with specialized tooling for high-temperature alloys.
Quality Focus
Rigorous quality control processes ensuring every component meets exact specifications.
Fast Turnaround
Efficient production processes delivering high-quality Haynes 230 parts on schedule.
Quality Assurance
Rigorous Testing and Certification
Frequently Asked Questions
Is Haynes 230 magnetic?
What is Haynes 230 metal?
Is Inconel 718 better than Haynes 230?
What is the difference between Haynes 188 and 230?
What is the difference between Haynes 230 and 282?
Ready to Start Your Haynes 230 Project?
Get expert manufacturing solutions for your high-temperature alloy requirements
