Surface Finishing Solutions
Enhance functionality, aesthetics, and performance with our advanced surface finishing technologies. We deliver precise, consistent, and application-specific surface treatments for critical components across industries.
Finishing Processes
Mechanical Finishing
Physical surface modification processes that alter texture, remove material, or create specific patterns.
- •Precision Grinding
- •Lapping
- •Polishing
- •Micro-Blasting
Chemical Finishing
Chemical processes that modify surface properties through reactions or material deposition.
- •Electropolishing
- •Passivation
- •Chemical Etching
- •Black Oxide
Surface Coatings
Application of specialized materials to enhance surface properties and performance.
- •PVD Coating
- •Hard Anodizing
- •Electroless Nickel
- •DLC Coating
Surface Quality Verification
Our comprehensive inspection capabilities ensure surface finishes meet exact specifications and performance requirements.
Certifications
ISO 9001:2015 Quality Management System
AS9100D Aerospace Quality Standard
ISO 13485 Medical Device Quality System
NADCAP Surface Enhancement Accreditation
Inspection Methods
Profilometry
- • Contact and non-contact surface measurement
- • Roughness parameters (Ra, Rz, Rq, etc.)
- • Waviness analysis
- • 3D surface mapping
Optical Inspection
- • Surface defect detection
- • Pattern verification
- • Color and appearance evaluation
- • Automated visual inspection
Material Testing
- • Coating adhesion testing
- • Hardness measurement
- • Wear resistance evaluation
- • Corrosion testing
Dimensional Verification
- • Pre/post-process dimensional comparison
- • Coating thickness measurement
- • Geometric tolerance verification
- • CMM inspection
Inspection Process
Surface finishing services—what we apply and when
Surface finishing changes corrosion resistance, wear, conductivity, cosmetics, or friction after machining or molding—anodize, plating, passivate, powder, polish, bead blast, and more.
Choose a finish quote with the parent part RFQ so masking, rack marks, and dimensional growth are planned—not discovered at receiving.
Partsproto coordinates finishing in China for overseas buyers; critical dims before/after finish should be stated on the print.
- → Anodize / hardcoat on aluminum
- → Zinc, nickel, or other plating on steel
- → Passivate stainless; black oxide
- → Cosmetic blast / polish / brush
Finishing workflow
Spec & mask plan
Confirm finish type, thickness, color, and keep-out zones.
Pre-clean
Machine oils removed; plug threads if required.
Finish process
Anodize/plate/passivate/blast as ordered.
Post-check
Thickness, color, adhesion sampling as scoped.
Pack
Scratch protection for cosmetics; export labels.
DFM tips for surface finishes
- •Call thickness and which dims are before vs after finish.
- •Mark masking on threads, ground fits, and electrical grounds.
- •Hard anodize grows and can crack sharp edges—radii help.
- •Different alloys anodize to different colors—name the alloy.
- •Cosmetic class: define viewing distance and reject criteria.
Inspection & QC on finishes
- ✓Thickness sampling when specified.
- ✓Visual against agreed cosmetic standard.
- ✓Adhesion / tape tests when required.
- ✓Salt spray or other tests only when contracted.
- ✓Before/after critical dim checks when growth matters.
Lead time & batch sizing
Many anodize/passivate lots add several days to machining lead time; specialty plating and colors can add more. Batch with other parts when possible. Tell us if finish is on the critical path for your overseas launch.
Surface finishes FAQ
Can you match a color chip?
Often yes for anodize/powder within process limits—send a chip and alloy.
Will plating change thread fit?
Yes if not planned. Tell us sequence (cut undersize vs chase after).
Do you finish parts machined elsewhere?
Sometimes—send material, current state, and print. We may require a sample.
Export packing for cosmetics?
Yes—layer films and edge protection for overseas freight.
Ready to Enhance Your Component Surfaces?
Our surface finishing expertise can help you achieve optimal performance, appearance, and durability for your components.
